Flake Color Sorter ToronGV Series
Flake Color Sorter ToronGV Series delivers high-precision sorting with advanced imaging technology, multi-stage processing, and fast throughput. Engineered for efficiency and accuracy, it’s ideal for separating plastic flakes by color with minimal energy use.
Main Applications
- Identify and eliminate opaque and black flakes from mixed-color flakes.
- General color sorting includes single-sided and double-sided colored plastic flakes.
- Remove opaque or differently colored flakes from high-quality clear or blue-white flakes.
- Detect and extract black materials from PC alloy, PC/PP/PS/ABS, and other blends.
- Separate clear and white HDPE flakes and sort different colored flakes from mixed ground HDPE scrap.
Color Sorting Version 3.0
The S-Class professional vision system features high-definition imaging and a 3D surround-recognition lens, enabling precise detection of subtle color variations to meet a wide range of color sorting requirements.
High and Stable Throughput
High-throughput feeding with multiple chute sorting and an anti-blocking material design supports extended unmanned operation—perfectly suited to meet your production demands.
Flexible Support
Supports standard sorting, reverse sorting, single sorting, re-sorting, and up to five sorting cycles. Highly versatile and easily adaptable to your specific process—significantly reduces energy consumption.
High Accuracy
The high-speed sensor, paired with a rapid-response chip and advanced guidance system, delivers sorting accuracy rates of up to 99.8%.
| Model | ToronGV5 | ToronGV6 | ToronGV7 | ToronGV8 | ToronGV10 | ToronGV12 |
|---|---|---|---|---|---|---|
| Accuracy (%) | >99.8% | >99.8% | >99.8% | >99.8% | >99.8% | >99.8% |
| Throughput (T/H) | 1.8–3.5 | 2–4 | 2.8–5.6 | 3–6 | 4–8 | 5–10 |
| Air Consumption (m³/min) | <2.5 | <3 | <3.5 | <4 | <5 | <6.5 |
| Power (kW) | 3.7 | 4.4 | 5.2 | 5.9 | 7.3 | 8.7 |
| Voltage/Frequency | AC220V/50HZ (110V is also available) | |||||
| Air Pressure (Mpa) | 0.6~0.8 | 0.6~0.8 | 0.6~0.8 | 0.6~0.8 | 0.6~0.8 | 0.6~0.8 |
| Weight (KG) | 1300 | 1450 | 1600 | 1700 | 2050 | 2250 |
| Dimension (mm) (L*W*H) | 2348 x 1829 x 1887 | 2663 x 1829 x 1887 | 2978 x 1829 x 1887 | 3293 x 1829 x 1887 | 3933 x 1829 x 1887 | 4563 x 1829 x 1887 |
Note: Parameters listed are for reference only and may vary depending on the application and feed conditions.
